RHEOMETERS

Stress-Controlled Rheometers

Rheometer DMA-850 (TA instruments, USA)

  • Temperature: -90 – 600 ºC
  • Immersion clamps
  • Single/dual cantilever, compression, 3-point bending and dust clamps
  • Moisture control
  • Oven + chiller



Rheometer DHR-3 (TA instruments, USA)

  • Double peltier
  • Oven + Chiller
  • Temperature: -60 – 400ºC
  • Sensors: Plate-Plate, Cone-Plate, Couette.
  • Flow, oscillatory and transitory test
  • Extentional for solids materials
  • Double wall-ring geometry available

Mars 40 (Haake, Germany)

  • Temperature: -30-150ºC
  • Sensors: Plate-Plate, Cone-Plate, Couette
  • Flow, oscilatory and transitory tests

AR2000 (TA instruments, USA)



  • Sensors: Plate-Plate, Cone-Plate.
  • Flow, oscilatory and transitory tests.
  • Temperature: -10-150ºC

Extensional Rheometer

CaBER 1 (Haake, Germany)



  • Temperature: 0-80ºC
  • Extensional capillary-roture tests
        •

DLS SYSTEMS

Malvern Mastersizer 2000 (Malvern, UK) (CITIUS)



  • Particle size distribution.
  • Range: 20mm (0.01-1000μm
  • Dispersants: Air/water



Zetasizer (Malvern, UK) (CITIUS)



  • Zeta potential
  • Particle nanometer determination
  • Temperature control

Turbiscan (Formulation, France)



  • Light scattering measurements
  • Backscattering sensor
  • Tube lenght 65mm

INTERFACIAL CHARACTERISATION

Sigma 701 Tensimeter (KSV, Finland)



  • Temperature: 0-90ºC
  • Range: 1-100m mN/m
  • Surface pressure measurements

DEVELOPMENT OF BIO-BASED MATERIALS

Polylab Q (Haake, Germany)



  • Torque and temperature monitor
  • Rotor: Roller 600
  • Volume mixing chamber: 73 cl
  • Ratio speed: 0-200 rmp

MiniJet II (Haake, Germany)





  • Injection mould device
  • Max. Temperature Mould: 400ºC
  • Max. Temperature Camber: 250ºC
  • Max. Pressure: 1200 Bar

REG4LIFE (regemat3d, Germany). 3D-Printing

  • Resolution real in the X e Y axis (spindel movement) = 150 μ m (0.15mm) | Resolution in Z = 400 nm (0,4 microns)
  • Theoretical resolution in the X and Y axis = 1.875 micras – 1875 nm
  • Thermoplastic extruder Nozzle output diameter 0,4 mm.
  • Syringes: Several output diameters 0,15 mm, 0,58 mm, 1,20 mm

Fluidnatek LE-50 (Bioinicia, Spain). Electrospinning

  • AC bench unit for temperature and humidity control
  • Flow regulation
  • Rotating collectors with scanning motion emitter
  • Extraction fan to exhaust solvent vapours
  • Availability of multi-nozzle

EMULSIFICATION DEVICES

Ultraturrax devices (T25 and T50)

Silverson-L5M





  • Rotor-Stator Homogenizer.
  • Rotation speed: 100-8000rpm.

Emulsiflex-C5-Avestin



  • Hight-pressure Homogenizer
  • Pressure: 2.7-3.5MPa; Capacity: 1-5 L/h
  • Minimun volume: 7mL

OTHER AVIABLE FACILITIES

  • Microscopy

    • SEM/CryoSEM
    • TEM/CryoTEM
    • Confocal
    • Optical

  • Ovens

    • Drying oven 2000381 (Selecta)
    • Incubator UN55 (Memmert)

  • Ubbelohde (Scott, Germany)

    • Liquid viscosity measurement.
    • Temperature range: 0-90ºC

  • Balls viscosimeter (Fungilab, USA)

    • Liquid viscosity measurement.
    • Temperature range: 0-90ºC.

  • MiniProtean IV Cell (Bio-Rad, USA)

    • SDS-PAGE Electrophoresis

  • Ultra-High-Pressure Reactor (UHP prototype)

  • 3D Bioprinter (Regemat REG4LIFE)

  • UV chamber (Biotech Bio-Link Crosslinker BLX-254)

  • Selecta centrifuge (BL-S)

  • Freezer Equitec (-40ºC)

  • Rotatory evaporator (Buchi)

  • pH meters (Crison)

  • Conductímeter Crison GLP32 (Crison Instruments S.A.)

  • Densimeter Metler Toledo (Densito 3P)

  • UV spectrophotometers

  • UV Tecan Multimode Plate Reader (Infinite 200 PRO)

  • Potentiometric Titrator (Metrohm 902 Titrando)

Lista de reactivos

We like to keep the lab tidy and the reagents up to date. Please, if you buy new reagents, number them and include them in the list, so that all members of the group can optimise resources. If you cannot edit the document, please, contact to the administrator.

Reagent list link
